Multispectral Submersion Classification of Water Soldier in Drone Imagery

Overview

In the previous phase of the project, Saiwa developed a high-resolution RGB-based detection model capable of identifying Stratiotes Aloides (Water Soldier) from drone orthophotos. However, while RGB imagery provides sufficient spatial detail for detection, it does not reliably indicate whether a detected plant is positioned above or below the water surface. Spectral differences related to water absorption and reflectance—particularly in the Near-Infrared (NIR) range—provide additional discriminatory power for this classification task.
The 2026 project therefore introduces multispectral analysis not for detection, but specifically for submersion status classification.

Problem Statement

Although high-resolution RGB orthophotos enable accurate detection of Water Soldier regardless of its position relative to the water surface, determining vertical status (above vs. below water) remains challenging using RGB data alone.
Key challenges include:

• Limited spectral contrast in RGB bands between emergent and shallow submerged vegetation
• Subtle visual differences under varying illumination conditions
• The need for pixel-level correspondence between RGB detections and NIR measurements
  A robust framework is required to combine precise RGB-based detection with spectral cues from NIR imagery.

Project Goals

The primary objectives of this phase are:

1. Maintain high-precision RGB-based detection of all visible Water Soldier specimens
2. Accurately align RGB orthophotos with NIR imagery through geometric registration
3. Extract spectral indicators from NIR data to distinguish emergent from submerged vegetation
4. Develop a classification model that assigns a submersion label (above-water / below-water) to each detected instance

Solution Approach

1. RGB-Based Detection (Baseline)

All plant detection continues to rely exclusively on high-resolution RGB orthophotos. The trained deep learning model identifies Water Soldier instances regardless of submersion depth, leveraging clear-water visibility conditions.

2. Cross-Sensor Image Registration

To incorporate spectral information, RGB orthophotos are geometrically aligned with NIR imagery using feature-matching and homography-based transformation techniques. This ensures pixel-level correspondence between detection outputs and multispectral data.

3. Spectral Feature Extraction for Submersion Classification

For each RGB-detected instance, spectral features are extracted from the aligned NIR layer. Because water strongly absorbs NIR radiation, emergent vegetation exhibits significantly higher reflectance than submerged vegetation. These differences form the basis of classification.
Relevant features may include:

• NIR reflectance intensity
• RGB–NIR band relationships
• Vegetation indices incorporating NIR

4. Submersion Status Classification

A supervised machine learning classifier is trained using labeled data (field validation and expert annotations) to determine whether each detected specimen is above or below the water surface.
The final output preserves the original RGB detection geometry while adding a submersion status attribute.

Expected Impact

By separating detection (RGB-based) from submersion classification (NIR-assisted), this approach maintains high spatial accuracy while introducing reliable vertical status estimation. The enhanced workflow enables more informed management decisions, supports targeted interventions, and strengthens long-term monitoring of invasive aquatic vegetation.
